Pressed Steel Process and Shipping Reels

Pressed steel reels for wire drawing, bunching, spooling, and shipping applications are manufactured to industry standard and custom sizes. The steel reels are manufactured using high-grade steel and assembled using high quality robot welding to ensure consistent quality and reliability.

SW - Single Wall Flange 8 Ribs High strength process reels Curly edge for increased strength 8 stiffening ribs for flange sturdiness Flange diameters 300 – 1250 mm (12" – 49") Steel up to 6 mm (1/4") thickness
SW - Single Wall Flange 12 Ribs Light to medium duty shipping reel Curly edge for increased strength 12 stiffening ribs for flange sturdiness Flange diameters 300 – 800 mm (12" – 31") Steel up to 3 mm (1/8") thickness
DW - Double Wall Flange Reel Heavy duty process reel 2 flange skins for minimal flange deflection Curly edge for increased strength Drum reinforcements for high tension spooling Machined winding surfaces for high speed spooling Dynamically balanced
HD – Heavy Duty Double Flange Heavy duty process reel 2 flange skins with lateral flange reinforcements Drum reinforcements for high tension applications Flange diameters 610 – 1500 mm (24” – 60”)
KR – Conical Steel Reels Conical flange and/or drum constructions Ideal for high speed un-winding applications Machined winding surfaces Customizeable sizes
Finishing Powder-coated, epoxy painted, galvanized Stenciling, embossing, and custom logos
